Characteristics

Material Of Construction - Motor:

• Oil Seal : Nitrile butyl rubber
• Motor Shaft : SS-420
• Motor Body Pipe : SS-304
• Motor Bush : LTB-4
• Thrust bearing assembly : SS - 420
• Diaphragm : High Nitrile Butyl Rubber
• Housing Set : Cast Iron

Material Of Construction - Pump:

• Check Valve Housing : Cast iron
• Outer Shell : SS-304
• Impeller : Noryl
• Bowl : Noryl
• Counter Bush : LTB-4
• Pump Bush : NBR / LTB 4
• Pump Sleeve : SS-410
• Suction : Cast iron
• Pump Shaft : SS-410
• Coupling / Pump Couple : SS-410

Salient Features :

• Motor portion covered with corrosive resistance Stainless steel SS-304
• More durability and hygiene
• High operating efficiency
• Specially designed thrust bearing to withstand high axial thrust load
• Extremely hardwearing water lubricated bearing
• Thread type motor construction ensures service feasibility
• Specially designed Deep Drawn type pump ensures perfect alignment and Thereby increases the life of the pump set
• Designed for wide voltage operation
• Best alternative for JET & Compressor pump set
• Additional intermediate bearing in higher stage pumps.
