Characteristics

Material Of Construction - Motor:

• Oil Seal : Nitrile butyl rubber
• Motor Shaft : SS-420
• Motor Body Pipe : J4
• Motor Bush : LTB-4 / Teflon
• Thrust bearing assembly : SS - 420 & Carbon
• Diaphragm : High Nitrile Butyl Rubber
• Motor Base : Cast Iron
• Housing Set : Cast Iron

Material Of Construction - Pump:

• Check Valve Housing : Cast iron / SS – 304
• Check Valve : SS-410 / Nylon
• Impeller : SS-304 / SS-410
• Bowl : SS-304 / Cast Iron
• Counter Bush : SS-410 / SS - 304
• Pump Bush : NBR / LTB 4
• Pump Sleeve : SS-410
• Suction : Cast iron / SS - 304
• Pump Shaft : SS-410
• Coupling / Pump Couple : SS-410

Salient Features :

• SS-304 Grade investment casting bowl and SS-304 grade impeller in radial flow series
• 20 Mtr. Head per stage in radial flow series
• Specially designed high performance thrust bearing (SS-420 Tilting pad with carbon plate) to with stand axial thrust loads
• Dynamically balanced rotating parts ensures minimum vibration and longer life
• Motor portion covered with corrosive resistance Stainless steel J4 shell
• More durability and hygiene
• High operating efficiency
• Special designed thrust bearing to withstand high axial thrust load
• Extremely hardwearing water lubricated bearing
• Thread type motor construction ensures services feasibility
• Specially designed Deep Drawn type pump ensures perfect alignment and Thereby increases the life of the pump set
• Designed for wide voltage operation
• Best alternative for JET & Compressor pump set
• Additional intermediate bearing in higher stage pumps
• Fully SS Pumps are available
